For use as wall absorbers together with a sound absorbing ceiling, to achieve excellent acoustic properties in the room. Ecophon Akusto™ Wall A has an exposed profile system. The system consists of Ecophon Akusto™ Wall A panels and Ecophon Connect profile systems, with an approximate weight of 4 kg/m². The panels are manufactured from high density, 3rd generation glass wool. The visible surface has a glass fibre fabric (Texona) or an impact resistant glass fibre fabric (Super G), and is also available with a painted surface (Akutex™ FT). The back of the panel is covered with glass tissue. The edges are natural. For best performance and system quality, use Ecophon Connect grid and accessories. The profiles are manufactured from galvanized steel (Connect Channel trim) or aluminum (Connect Thinline).

For use as wall absorbers together with a sound absorbing ceiling, to achieve excellent acoustic properties in the room. Ecophon Akusto™ Wall C has a concealed grid and the bevelled edges create a narrow groove between each panel. The system provides extensive design possibilities. The system consists of Ecophon Akusto™ Wall C panels and Ecophon Connect profile systems with an approximate weight of 5 kg/m². The panels are manufactured from high density, 3rd generation glass wool. The visible surface has a glass fibre fabric (Texona) or an impact resistant glass fibre fabric (Super G), and is also available with a painted surface (Akutex™ FT). The back of the panel is covered with glass tissue. The edges are painted, and the front surface is partly covering the long edges. The Texona gamma version offers a reflecting surface, see absorption diagram. For best performance and system quality, use Ecophon Connect profiles and accessories, which gives a lot of design possibilities. The profiles are manufactured from extruded aluminium.

Ecophon Akusto Screen A is a highly efficient sound absorbing screen which together with a sound absorbing ceiling gives excellent room acoustics in open areas like open-plan offices. Akusto Screen is a vital part of an acoustic solution for TABS (Thermally Activated Building Systems) buildings. It has the same Texona surface as Akusto Wall™ which will keep your colour design consistent. Ecophon Akusto Screen A has a high density absorber in 3rd generation glass wool and has excellent sound-reducing properties. It is set in a naturally anodised aluminum frame and both sides have a glass fibre fabric surface (Texona). The approximate weight is 24-44 kg. It is also possible to get a 6 mm thick and 400 mm high clear glass pane on top of the screen, total height of screen 1820 mm. The feet are naturally anodised aluminum.

To increase the sound absorption in the room this system gives you the possibility to install Ecophon Akusto One SQ on the wall. The systems give design possibilities, working with different formats and colours to create various patterns. There are three fixings for Akusto One SQ, Connect™ One trim, Connect™ One hook fixing or Connect™ One fixing. Akusto One SQ is available in various sizes with a weight of 2,0-4,5 kg. The panel is manufactured from high density, 3rd generation glass wool. The visible surface has a glass fibre fabric Texona in colours and is also available with a painted surface (Akutex™ FT). The back of the panel is covered with glass tissue. The edges are straight cut and painted in white or grey.
