[LIST] Movable sound insulated partition Sound insulation value up to Rw 55 dB (acc. EN 20140 laboratory value) Parking layout GRD 0 - Single 1-point suspension. Parking 90° to partition axis Element thickness 100 mm Element width from 600 mm to 1250 mm Clear height from 2000 mm to 4100 mm (dependen on panel weight) Cleaer height MOVEO Glass from 2000 mm to 4000 mm Operation mode ComforTronic (electrically controlled sealing strip extension and retraction) Optional element types for pass doors and glass panels [/LIST] dormakaba - www.dormakaba.com

[LIST] Movable sound insulated partition Sound insulation value up to Rw 57 dB (acc. EN 20140 laboratory value) Parking layout GRD 1 - Double 2-point suspension. parking 90° inside partition axis Element thickness 100 mm Element width from 600 mm to 1250 mm Clear height from 2000 mm to 14500 mm (higher on request) Operation 1) Standard operation: manuall 2) Comfort operation: semi-automatic ComforTronic (electrically controlled sealing strip extension and retraction) Optional element types for pass doors [/LIST] dormakaba - www.dormakaba.com

[LIST] Horizontal sliding walls Fully glazed with glazing rails (100 mm) top and bottom The sliding panels of the HSW-G glass sliding wall provide continuous and transparent glass surfaces without any lateral frame elements. All functional components are concealed in the top and bottom door rails, while convenient clip-on covers in various materials and colour shades cover all visible surfaces. Ideal for Shopfront, balcony, internal room division Different parking layouts available Glass types Toughened safety glass 10/12 mm, toughened laminated safety glass 12, 13.5 mm Max. system height 4000 mm Max. panel width 1250 mm (1100 mm). The individual panels can also be of differing widths. Max. panel weight 150 kg (depends on type of panel) Panel types Single action end panel, Double action end panel, Bedstop end panel, Single action sliding panel, Double action sliding panel [/LIST] dormakaba - www.dormakaba.com

[LIST] Movable sound insulated partition Sound insulation value up to Rw 57 dB (acc. EN 20140 laboratory value) Parking layout GRD 0 - Single 1-point suspension. Parking 90° to partition axis Element thickness 100 mm Element width from 600 mm to 1250 mm Clear height from 2000 mm to 4100 mm (dependen on panel weight) Operation 1) Standard operation: manuall 2) Comfort operation: semi-automatic ComforTronic (electrically controlled sealing strip extension and retraction) Optional element types for pass doors [/LIST] dormakaba - www.dormakaba.com

[LIST] Horizontal sliding wall with single-point stainless steel fixings The HSW-GP is characterised by the use of MANET single-point fixings in combination with a standard track rail. The system’s high-quality stainless steel components and flush-mounted single-point fixings perfectly match the demands of modern architecture. Different parking layouts available Glass types 10 mm or 12 mm toughened safety glass Max. system height 3000 mm Max. panel width 1200 mm. The width of all panels must be uniform. Max. panel weight 100 kg (depends on type of panel) Panel types Single action end panel, Double action end panel, Fixed screen, Sliding panel Suitable for both inline and curved configurations. Benefits: Minimal hardware maximizes all-glass look. No floor track. Stainless steel fittings provide flush-mounted attachments compatible with contemporary architecture. [/LIST] dormakaba - www.dormakaba.com

[LIST] Energy saving automatic sliding door system DORMA's ST Flex Green satisfies the requirements of the latest energy-saving building regulations for England and Wales - Approved Document L (2010) while also harmonizing perfectly with the existing DORMA sliding door range. Ideal for Exterior doors, porch Max. system width 6250 mm Max. passage width 3000 mm Max. passage height 3000 mm Energy Efficiency EnEV 2014, UD-Values from 1,4 to max.1,8W/m²K Thermal Insulation EN ISO 10077 Drive DORMA ES 200, ES 200-D Durability Min. 1000000 cycles Escape Route ES 200-2D Certification Fabrication DIN ISO 9001, Environmental product declarations ISO 14025, DIN 18650 and EN 16005 Benefits are Excellent insulation features thanks to interlocking side seals and top and bottom seals, Suitable for use on emergency escape routes, Activation via radar, push pad or access control (further options on request) [/LIST] dormakaba - www.dormakaba.com

[LIST] Revolving doors with 3 leafs The KTV revolving door range is designed for installation in entrance areas where interior environmental control coupled with elegant aesthetics are desired. Available as Manual, Automatic, Positional or Servomatic, the KTV range offers flexibility in design and function. Operation Modes Manual, Automatic, Positional and Servomatic operation Diamater any from 2000 mm to 3400 mm. Standard fixed diameters of 3600 mm and 3800 mm are also available. Floor mounted or ceiling mounted drive units for powered doors Glazed or solid canopy Robust framing or fine frame option Optional: Night shields for additional protection Integrated with DORMA CODIC MasterCard or MATRIX Professional Access Control solutions Certification BS EN 16005 Benefits are flexible design options to meet project specific requirments, DORMA KTV revolving doors effectively reduce noise, dust and dirt as well as greatly contributing to a reduction in building climate control when compared with conventional automatic doors [/LIST] dormakaba - www.dormakaba.com

[LIST] Revolving doors with 4 leafs The KTV revolving door range is designed for installation in entrance areas where interior environmental control coupled with elegant aesthetics are desired. Available as Manual, Automatic, Positional or Servomatic, the KTV range offers flexibility in design and function. Operation Modes Manual, Automatic, Positional and Servomatic operation Diamater any from 2000 mm to 3400 mm. Standard fixed diameters of 3600 mm and 3800 mm are also available. Floor mounted or ceiling mounted drive units for powered doors Glazed or solid canopy Robust framing or fine frame option Optional: Night shields for additional protection Integrated with DORMA CODIC MasterCard or MATRIX Professional Access Control solutions Certification BS EN 16005 Benefits are flexible design options to meet project specific requirments, DORMA KTV revolving doors effectively reduce noise, dust and dirt as well as greatly contributing to a reduction in building climate control when compared with conventional automatic doors. [/LIST] dormakaba - www.dormakaba.com

[LIST] Low Energy electromechanical swing door operator The ED 100/250 A swing door operator is especially suitable for exterior doors that are subjected to varying wind loads and for interior doors separating rooms where different air pressures prevail. The Wind Load Control monitors the actuation speed, keeping it constant at the preset value. Dimension 685 x 70 x 130 mm Max. Door Weight 160 kg (ED 100), 400 kg (ED 250) depending on the door leaf width Max. Door Width 1100 mm (ED 100), 1600 mm (ED 250) Max. Opening Angle 110° Hold-open time 0 to 30 seconds Push or Pull version for single or double leaf doors Activation via radar, push pad, linking to access control systems and other actuation devices Tested to 1,000,000 cycles Low noise levels through multi–stage gearing Suitable for use on emergency escape and fire doors Suitable for use on projects to meet EN 16005 [/LIST] dormakaba - www.dormakaba.com

[LIST] Movable sound insulated partition Sound insulation value up to Rw 57 dB (acc. EN 20140 laboratory value) Parking layout GRD 5 - Double 2-point suspension: parking 90° parallel partition axis Element thickness 100 mm Element width from 600 mm to 1250 mm Clear height from 2000 mm to 14500 mm (higher on request) Operation 1) Standard operation: manuall 2) Comfort operation: semi-automatic ComforTronic (electrically controlled sealing strip extension and retraction) Optional element types for pass doors [/LIST] dormakaba - www.dormakaba.com

[LIST] Anti-Pinch Door System Secure, safe and functional Enables building of frameless glass swing doors The pivot point is located centrally in the glass axis and close to the glass edge for anti-pinch/anti-nip safety. Prevents the risk of trapped fingers Fittings for 10 mm and 12 mm glass along with a choice of pull handles or lock/lever handle combinations. Enables building of frameless glass swing doors [/LIST] dormakaba - www.dormakaba.com

[LIST] Invisible closing function Max. door panel weight 85 kg Successfully completed 500,000 operating cycles in its endurance test Discrete presence and easy integration Unobtrusive design Quality tested [/LIST] dormakaba - www.dormakaba.com

[LIST] Automatic bi-folding door with slender fine-frame profiles The FFT bi-folding door is especially suitable for areas where space is tight and no standard sliding door solutions may be installed. The door panels are equipped with fine-frame profile systems to protect the double glazing. Minimal space requirement when opened thanks to bi-folding door panels, Slender profiles allowing large glass surfaces, Sensitive force monitoring, Versions with or without floor-integrated guide rails Clear passage width from 800mm to 2000mm (FFT) and 900mm to 2000mm (FFT-F) Clear passage height from 2100 mm to 2500 mm Drive ES90, ES 90-FST (FFT-F) Tested DIN 18650 and AutSchR. Approval for application in emergency exits and escape routes (FFT-F). Optional floor locking device, Emergency manual lock release, Sensors DIN 18650 [/LIST] dormakaba - www.dormakaba.com

[LIST] Balance Space Saving Door RST RST-G: Fine framed with toughened glass giving the appearance of a swing door with minimum sweep area. RST-R: Robust extruded framing for high traffic and high usage projects where space is at a premium. Max. Clear Passage Height 2300 mm (RST-G), 2500 mm (RST-R) Max. Clear Passage Width 2000 mm Tested to DIN 18650 and suitable for application in emergency exits and escape routes Ideal for Exterior and interior doors in narrow passage areas, Public buildings and Barrier-free access Minimum space requirement for door leaves thanks to swivel and slide motion Installed beneath or in front of the lintel Activation via radar, push pad or access control Fitted with DORMA Prosecure sensors Available with or without a glazed fanlight [/LIST] dormakaba - www.dormakaba.com

[LIST] Concealed slide channel door closer with cam-action technology The DORMA ITS 96 door closer is designed for concealed installation in the door leaf and frame. Suitable for almost every type of door, it offers a wide variety of functions and flexibility combined with a high level of quality. Successfully third party tested to BS EN1154. CERTFIRE Approved CF 140 Universally suitable for single or double doors Concealed installation for Door leaf thickness ≥ 40 mm Adjustable Closing Force and Optional hold-open Unblemished appearance of prestige doors thanks to concealed installation Same slide channels and accessories for the ITS 96 EN 2-4 and EN 3-6 models Benefits: Optimum protection against vandalism thanks to concealed installation. Enhanced user convenience with low opening forces, fully controlled reliable closing and adjustable latch action [/LIST] dormakaba - www.dormakaba.com

[LIST] Cam Action Door Closer System The TS 93 cam action door closer system provides a high-quality architectural solution for all project application requirements, featuring the DORMA heart-shaped cam to ensure exceptional ease of opening. Dimension (EN 2-5/EN 5-7) Length 275/285 mm, Depth 53/62 mm, Height 60/71 mm Max. Door Leaf Width Standard Doors (EN 2-5/EN 5-7) 1250/1600 mm Max. Door Leaf Width External doors, outward opening (EN 2-5/EN 5-7) 1250/1600 mm Max. Door Leaf Width Fire and smoke check doors (EN 2-5/EN 5-7) 1250/1600 mm With adjustable power size, "thinking" backcheck and delayed action Suitable for all fixing positions For single- and double-leaf doors Modular system. The TS 93 series comprises a modular system which enables just a few door closer models to be combined with a number of different slide channels to meet virtually every conceivable functional requirement. Benefits: Clear product allocation ensures use of the right models for the right applications. Identical door closer model for single and double doors. Simple, fast installation [/LIST] dormakaba - www.dormakaba.com

Crossbar fittings for emergency exit doors. With this system, DORMA is able to offer a comprehensive range of high quality panic hardware fittings with horizontal and vertical locking for doors in emergency exits and escape routes – applications in which safety, reliability and aesthetic attractiveness are indispensable requirements. The Panic Hardware products of the series DORMA PHA 2000 and PHB 3000 have been tested to and certified compliant with EN 1125. All products meet the requirements of Annex ZA to EN 1125 and are therefore qualified to bear the mark of conformity. dormakaba - www.dormakaba.com

[LIST] Revolving doors of all-glass design DORMA three-wing and four-wing revolving doors break down the barriers to creativity in entrance design. Buildings are both aesthetically and functionally enhanced in the best possible way, thanks to the beautiful all-glass appearance of the DORMA KTV ATRIUM. Operation Modes Manual, Positional and Servomatic operation Diameter 2000 mm, 2200 mm, 2400 mm, 2600 mm or 2800 mm Passage Height 2100 mm to 2500 mm Floor mounted or ceiling mounted drive units for powered doors Glazed canopy Optional Night shields, Push bars, Wing locks Certification BS EN 16005 Benefits: Extensive design flexibility in terms of planning and technical requirements, Visually, technically and economically the ideal solution, Flexible design options to meet project specific requirments, Greatly improved building environmental control [/LIST] dormakaba - www.dormakaba.com

[LIST] Revolving doors with 3 or 4 leafs The KTV revolving door range is designed for installation in entrance areas where interior environmental control coupled with elegant aesthetics are desired. Available as Manual, Automatic, Positional or Servomatic, the KTV range offers flexibility in design and function. Operation Modes Manual, Automatic, Positional and Servomatic operation Diamater any from 2000 mm to 3400 mm. Standard fixed diameters of 3600 mm and 3800 mm are also available. Floor mounted or ceiling mounted drive units for powered doors Glazed or solid canopy Robust framing or fine frame option Optional: Night shields for additional protection Integrated with DORMA CODIC MasterCard or MATRIX Professional Access Control solutions Certification BS EN 16005 Benefits are flexible design options to meet project specific requirments, DORMA KTV revolving doors effectively reduce noise, dust and dirt as well as greatly contributing to a reduction in building climate control when compared with conventional automatic doors. [/LIST] dormakaba - www.dormakaba.com

[LIST] An unrivalled automatic sliding door operator Outstanding user convenience and unique operational behaviour characterize the automatic sliding door operator CS 80 MAGNEO. The door is driven by the magnetic and thus contactless shear wave of a linear DC motor. The CS 80 MAGNEO thus offers the twin benefits of almost silent operation and the ultimate in reliabilty. Available in 3 standard sizes and opening with from 665mm to 1125mm Dimension 62 / 75mm Height, 60 mm Width Max. Panelweight 80 Kg Tested DIN EN 1527 Adjustable hold-open times and speed Ideal for private living areas and offices Type-tested in compliance with DIN 18650, ANSI und BSI Benefits: Modular system, Simple installation, easy operation, Long operating life due to innovative technology, Easy mounting and comissioning due to Plug&Play technology, The system allows virtually any door to be configured as an automatic sliding door [/LIST] dormakaba - www.dormakaba.com

[LIST] Automatic sliding door system with slender fine-frame profiles Modern fine framed profiles combined with the DORMA ES 200 Automatic Sliding Door Operator to form a visually appealing complete door system with a variety of applications. In conjunction with other doors from the FLEX family (FLEX Green and FLEX SECURE) the system can be used to create a harmonious overall look. Ideal for Exterior doors, porch, public space, offices, healthcare and education projects Max. system width 6250 mm Max. passage width 3000 mm Max. passage height 3000 mm Energy Efficiency EnEV 2014, UD-Values from 1,4 to max.1,8W/m²K Thermal Insulation EN ISO 10077 Drive DORMA ES 200, ES 200-D Durability Min. 1000000 cycles Escape Route ES 200-2D Certification Fabrication DIN ISO 9001, Environmental product declarations ISO 14025, DIN 18650 and EN 16005, BS EN 16005, AutSchR Benefits are Excellent insulation features thanks to interlocking side seals and top and bottom seals, Suitable for use on emergency escape routes, Activation via radar, push pad or access control (further options on request). Ideal to meet the relative legislative requirements for disabled access in the UK and Ireland [/LIST] dormakaba - www.dormakaba.com

This complete sliding door system is a designer's delight combing the appeal of frameless door leaves and side panels with the performance of the ES 200 automatic sliding door operator. Ideal for use on offices, healthcare and education projects, as well as numerous other specifications. [LIST] Frameless door leaves with maximum visual transparency Suitable for use on emergency escape routes The full range of performance functions for the DORMA ES 200 automatic sliding door operator (tested to 1,000,000 cycles) Frameless door leaves with top and bottom rails or manet patch fittings Monitored battery back-up system Activation via radar, push pad or access control [/LIST] dormakaba - www.dormakaba.com

For high traffic environments, the “ST-S” combines the exceptional quality and performance of the DORMA ES 200 Automatic Sliding Door Operator with extruded aluminium framing. Robust framing for high traffic, high usage environments. Ideal for, but not limited to, use on Shopping/Retail projects, education, healthcare and transport hubs [LIST] Suitable for use on emergency escape routes The DORMA ES 200 automatic sliding door operator provides both quality and assurance, having been tested to 1,000,000 cycles Robust framed door leaves Monitored battery back-up system Activation via radar, push pad or access control Combined with laminated or toughened safety glass [/LIST] dormakaba - www.dormakaba.com

[LIST] Sliding door system with concealed carriers The AGILE 150 operating mechanism is completely concealed in the track, which measures only 63mm high, enabling sliding glass doors to retain their minimalist aesthetics. Glass sliding panels (up to 13.5mm) or wood (up to 40mm) Min. Operator dimensions height 43 mm, width 58 mm Max. panel weight 150 Kg (Agile 150) and 50 Kg (Agile 50) Min. panel width 500mm (Agile 50 and 150), 830mm (Agile 150 Dormotion L), 1160mm (Agile 150 Dormotion XL) Max. panel width 1200mm (Agile 50), 1500mm (Agile 150) Max. panel height 2500mm (Agile 50), 3000mm (Agile 150) Gap size glass/wall or glass/glass between 12 mm ( 13,5 mm glass thickness) and 18 mm (8 mm glass thickness) Toughened safety glass and Toughened laminated safety glass (Agile 150) between 8mm and 13.5mm Smoothness Class 3 (DIN EN 1527) Clamp-type fittings – no glass preparation is required Also suitable for wet rooms (BS EN 1670, Class 4) Tested for more than 100,000 operating cycles (performed to BS EN 1527) Benefits: DORMA Agile 150 still can be used where space is limited. Installation and use in humid areas. The AGILE floor guide offers an impressive combination of effective functionality and attractive design. With clamp-type fittings, the need to drill and cut the glass is eliminated. Fast, simple fitting, saving time and money. [/LIST] dormakaba - www.dormakaba.com

[LIST] Manual Sliding Door System Robust clamp-type carriers designed for glass or timber panels up to 120 kg. The visible system surface and finish is achieved on the basis of clip-on cover profiles. Max. sliding panel weight 80 kg (Syncro version) / 120 kg (glass or timber panels with two carrier) / 150 kg (glass panels with three carriers) Glass thicknesses sliding panel 8 mm, 10 mm and 12 mm Timber thickness sliding panel from 26 mm to 35 mm Dimensions Height 143 mm, Width 52/73 mm Clamp-type fittings – no glass preparation required End stop and holder Syncro feature: Opening one panel automatically opens the other Benefits: With clamp-type fittings, the need to drill and cut the glass is eliminated, Fast and simple fitting, saving time and money, particularly suitable for applications in which convenience needs to be married to style [/LIST] dormakaba - www.dormakaba.com

[LIST] Horizontal sliding wall with double glazing and a surrounding frame made of thermally insulated profiles With their versatile glass partitions, DORMA provides the ideal solution for linking or separating rooms according to your individual requirements. Thanks to a large range of components, these versatile systems add security, provide noise insulation, and cut energy costs - just as desired. Ideal for Shopfront, Shopfront with thermal insulation requirements, Balcony Different parking layouts available Glass types Toughened laminated safetyglass, 8 mm - 49 mm. Insulating glass on request Max. system height 3000 mm Max. panel width 1100 mm Max. panel weight 120 kg (depends on type of panel) Panel types Bedstop end panel, Single action sliding panel, Sliding panel Sound Insulation DIN 52 210 Teil 3, 27 dB Thermal Insulation DIN EN ISO 10077-1 and DIN EN ISO 10077-2 Ventilation Class 2 (DIN EN 1026) Wind load resistance Class B3 (DIN EN 12211) [/LIST] dormakaba - www.dormakaba.com

[LIST] Horizontal sliding wall with single-point stainless steel fixings Ideal for Shopfront, Shopfront with thermal insulation requirements, internal room partition The HSW-GP is characterised by the use of MANET single-point fixings in combination with a standard track rail. The system’s high-quality stainless steel components and flush-mounted single-point fixings perfectly match the demands of modern architecture. Different parking layouts available Glass types Toughened safety glass 8 mm to 24 mm, Toughened laminated safety glass 12 mm to 28mm. Insulating glass on request Max. system height 3000 mm Max. panel width 1100 mm. Max. panel weight 120 kg (depends on type of panel) Panel types Bedstop end panel, Single action sliding panel, Sliding panel [/LIST] dormakaba - www.dormakaba.com

Designed for demanding specifications, the accessories in the DORMA Studio range will give reliable service in busy environments. The range of locks, levers handles and hinges is wide enough to offer plenty of scope for design creativity. DORMA can offer years of experience with constructional glass, and has developed its fittings so that the glass preparation is reduced to the quick and easy drilling of a few holes. The carefully thought out design ensures maximum contact area for optimum clamping efficiency. [LIST] Simple glass preparation Firm fixing Reliable operation Extensive range of finishes and colours [/LIST] dormakaba - www.dormakaba.com

[LIST] Horizontal sliding wall with single-point stainless steel fixings Variants FSW-G, FSW-C and FSW-C plus. The door rails of the FSW-G are connected to one another at the top and bottom by hinges, and its panels are suspended at the end of the top rails. The closed wall transforms effortlessly into a compact parked stack when required - without the need for a separate stacking track. Ideal for Shopfront, Balcony, Internal room partition Different parking layouts available Glass types Toughened safety glass 10/12 mm, Toughened laminated safety glass 12, 13.5 mm Max. system height 3000 mm Max. panel width 1200 mm. Max. panel weight 70 kg (depends on type of panel) Panel types Single action end panel, Double action end panel, Bedstop end panel, Sliding panel, Single action sliding panel (FSW-C plus) Benefits: No need for a separate stacking track. FSW system are visually compatible with the HSW-G panels. Both system types can use the same track rail construction and can be effectively combined within a single frontage. Consequently, an FSW system can also be complemented through the addition of a free-standing HSW double-action or single-action end panel. [/LIST] dormakaba - www.dormakaba.com

[LIST] Type: Manual sliding door system with self-closing function without external power supply. The door is opened and then closes under its own spring power – thanks to a bungee cord pulley system designed for glass doors up to 120 kg (single panel door) Opening: 1-Leaf, 2-Leaf, Telescopic Panel: Glass and timber with both light and heavy doors (50 kg–200 kg). Laminated safety glass (LSG) Damping: DORMOTION cushioning mechanism – panel is decelerated in both its opening and closing directions and then drawn automatically to the end position. No glass preparation Installation: Wall, ceiling, lintel, glass overpanel installation and suspended ceilings Side lights: Optional Standards: EN 1527 with 200.000 cycles The product will be available mid/end 2015 (depends on variant). [/LIST] dormakaba - www.dormakaba.com

[LIST] Burglar resistant fine framed automatic door system The ST FLEX Secure sliding door system has been especially designed to provide maximum security. The system offers an unparalleled level of security and meets the increasing demand of facility operators for a solution that combines the convenience of an automatic sliding door with additional anti-intruder and anti-vandalism protection. Key-Features are Secure 4-point locking device. Monitored battery back-up system suitable for use on emergency escape routes. Special burglar resistant laminated safety glass Double Panel: LW 1000 – 3000 mm, LH 2080 – 3100 mm, max. 2 x 160 kg Single Panel: LW 700 – 3000 mm, LH 2080 – 3100 mm, max. 1 x 200 kg Operator ES 200 and ES 200-2D, h/d 150 mm x 180 mm Resistance WK2/RC2 Glazing tested DIN EN 356, P4A: Security double-glazing (22 mm LSG), Mono safety glazing (10 mm LSG) May be fitted with DIN 18650 and EN 16005 compliant safety equipment Energy ENV 1627 to 1630 Durability Min. 1000000 cycles Benefits are no visible barriers (in contrast to similar security doorsets). Excellent intruder protection. Appealing fine frame profile. The full range of performance functions for the DORMA ES 200 automatic sliding door operator [/LIST] dormakaba - www.dormakaba.com

[LIST] Thermal insulated automatic folding door. Suitable for external doors or internal doors in narrow passageways The first folding door that provides for maximum clear opening width of 2.4m in tight spaces. FFT FLEX Green offers outstanding thermal separation, a quiet, dynamic operation and enhanced wind load resistance. It is particularly suitable for emergency exits and escape routes. Operator height 155 mm (internal view face) Profile system DORMA FLEX Green with thermal break Mounting method Passageway/corridor installation or wall/face-fixed installation, for doorsets that are either unilateral or bi-parting in their method of operation Suitable for emergency exits and escape routes in accordance with DIN 18650 and EN 16005 Max. opening width 2400 mm (bi-parting), 1200 mm (unilateral) Max. clear passage height 2500 mm Floor guide track surface or underfloor as required Electromechanical locking device optional, floor locks and hook latch lock optional [/LIST] dormakaba - www.dormakaba.com

[LIST] Horizontal Sliding Wall HSW EASY Safe, Standard Stacking Laminated safety glass with Clamp & Glue fixing technology Glass thicknesses from 10 to 19 mm Support profile for single-action and double-action pivoting-sliding panels with integrated slide channel Top rail can be optionally provided with an adhesive channel for the secure fixing of laminated safety glass Roller carrier mounting can be variably adjusted both at the support profile and at the door/glazing rail profile Combined with: Door Closers TS 92, ITS 96, ITS 96 2-4, BTS 80, BTS 84 Push handles, Office locks, center/corner locks, HSW-GP Double top and bottom brush seal profiles available Easy installation thanks to three-in-one multilock assembly Status indicator showing whether the panel is in the pivoting or sliding mode for enhanced safety The product will be available mid 2015. [/LIST] dormakaba - www.dormakaba.com

[LIST] Horizontal sliding wall with double glazing and a surrounding frame made of thermally insulated profiles Different parking layouts available Bottom profile Thermal break and water channel (optional) Track rail with optional thermal break Insulation value U of approx. 1,5 W/m²K (with standard insulating glass) Meets the requirements of the German Energy Saving Ordinance EnEV Combined with door closer types TS 92, ITS 96 3-6, Push handles, ISEO Multilock Pivoting-sliding panels equipped with an ITS 96 3-6 concealed door closer Operation Easy, one-handed single throw of the lock bar to switch between the door and sliding functions, with no bending and no crank operation 40% improvement in thermal separation value (compared to the predecessor model) Heat transfer coefficient in accordance with DIN EN ISO 10077-1 and 10077-2 Endurance DIN 1527 Class 3 (25000 cycles) for suspend sliding doors > 100kg Impact DIN EN 13049 Class 3 Corrosion DIN EN 1670 Class 3 The product will be available end 2015 [/LIST] dormakaba - www.dormakaba.com

[LIST] Housing made of stainless steel satin finish AISI 304. non-tiltable crossbars made of stainless steel satin finish AISI 304. With additional back plate made of stainless steel AISI 304. variant A: passage side inwards right. Function Type 2 power-assisted motion; servo positioning drive / 2 directions electrically controlled. Power supply 100–240 VAC 50/60 Hz Control system integrated in the unit. Prepared for the connection of signal lights. Doweled on finished floor level FFL, floor levelness according to DIN 18202 max. ± 2 mm. Not suitable for outdoor installation! Prot. class Housing IP33, components conducting supply voltage IP43. Suitable for escape routes if combined with emergency push button and escape route equipment (cf. general accessories). [/LIST]

[LIST] Housing made of stainless steel satin finish AISI 304. non-tiltable crossbars made of stainless steel satinfinish AISI 304. variant A: passage side inwards right. Function Type 0 manual motion; mechanically free in one direction / opposite direction blocked. Locked direction of use: exit accessible, entry locked Electric Control system integrated in the unit. Power supply 100–240 VAC 50/60 Hz Doweled on finished floor level FFL, floor levelness according to DIN 18202 max. ± 2 mm. Suitable for outdoor installation! Prot. class Housing IP33, components conducting supply voltage IP43. [/LIST]

[LIST] Aluminium housing coated in RAL 9006, base columns with flange plate in stainless steel AISI 304 satin finish. non-tiltable crossbars made of stainless steel satin finish AISI 304. variant A: passage side inwards right. Function Type 2 power-assisted motion; servo positioning drive / 2 directions electrically controlled. Power supply 100–240 VAC 50/60 Hz Control system integrated in the unit. Prepared for the connection of signal lights. Doweled on finished floor level FFL, floor levelness according to DIN 18202 max. ± 2 mm. Suitable for outdoor installation! Prot. class Housing IP33, components conducting supply voltage IP43. Suitable for escape routes if combined with emergency push button and escape route equipment (cf. general accessories). [/LIST]

[LIST] Passage width = 650 mm, total width = 1.050 mm, interlock height 1.020 mm, interlock length = 1.760 mm Housing made of stainless steel satin finish AISI 304. Two door leaves made of transparent polycarbonate, upper edge 900 mm. Stainless steel satin finish. Function Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Entrance sector monitored by a basic sensor system in compact overall length (fundamental single passage monitoring in both directions, security level 1). Protective device: rotation angle of the barrier door leaves monitored by the same sensor system. 2 operation modes are possible: Default position "day-operation" open: the door leaves close automatically if somebody tries to pass without authorisation. Default position "night-operation" closed: the door leaves open automatically for authorised persons in the passage direction and then close again after passage. In the case of a power failure: door leaves can be moved freely! Electric Control units and power supply unit are integrated in the unit. Power supply 100-120 V / 200-240 V 50-60 Hz Dowelled on finished floor level FFL. Not suitable for outdoor installation! Suitable for escape routes if combined with emergency push button and escape route equipment (cf. general accessories). [/LIST]

[LIST] Passage width = 650 mm, total width = 1.070 mm, interlock height 945 mm, interlock length = 1.660 mm Guiding elements made of stainless steel AISI 304, Ø 60 mm, with 10 mm tempered safety glass panels and AISI 304 stainless steel bar handle. Integrated sensor system in respective handrail (L = 1660 mm / W = 130 mm / H = 45 mm) Two door leaves made of transparent polycarbonate, upper edge 900 mm. Drive housing made of stainless steel AISI 304. Stainless steel satin finish. Function Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Entrance sector monitored by a basic sensor system in compact overall length (fundamental single passage monitoring in both directions, security level 1). Protective device: rotation angle of the barrier door leaves monitored by the same sensor system. 2 operation modes are possible: Default position "day-operation" open: the door leaves close automatically if somebody tries to pass without authorisation. Default position "night-operation" closed: the door leaves open automatically for authorised persons in the passage direction and then close again after passage. In the case of a power failure: door leaves can be moved freely! Control units and power supply unit are integrated in the unit. Power supply 100-120 V / 200-240 V 50-60 Hz Dowelled on finished floor level FFL Not suitable for outdoor installation! [/LIST]

[LIST] Passage width = 650 mm, total width = 1.070 mm, interlock height 945 mm, interlock length = 2.010 mm Guiding elements made of stainless steel AISI 304, Ø 60 mm, with 10 mm tempered safety glass panels and AISI 304 stainless steel bar handle. Sensor system arranged horizontally and vertically, mounted on the guiding elements. Stainless steel plates and infrared transmissible plastic covers are used to cover the sensors. Two door leaves made of transparent polycarbonate, upper edge 900 mm. Drive housing made of stainless steel AISI 304. Stainless steel satin finish. Function Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Entrance sector monitored by enhanced sensor system in optimised overall length and alignment (increased level of single passage monitoring in both directions, security level 2). Integrated protection against entry from below, identification of trolleys, detection of children. Protective device: rotation angle of the door leaves is monitored by the same sensor system. 2 operation modes are possible: Default position "day-operation" open: the door leaves close automatically if somebody tries to pass without authorisation. Default position "night-operation" closed: the door leaves open automatically for authorised persons in the passage direction and then close again after passage. In the case of a power failure: door leaves can be moved freely! [/LIST]

[LIST] Passage width = 650 mm, total width = 1.050 mm, interlock height 1.600 mm, interlock length = 2.050 mm Two door leaves made of transparent polycarbonate, upper edge 1.600 mm. Housing made of stainless steel satin finish AISI 304. base closed AISI 304. Stainless steel satin finish. Function Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Entrance sector monitored by enhanced sensor system in optimised overall length and alignment (increased level of single passage monitoring in both directions, security level 2). Integrated protection against entry from below, identification of trolleys, detection of children. Protective device: rotation angle of the door leaves is monitored by the same sensor system. 2 operation modes are possible: Default position "night-operation" closed: the door leaves open automatically for authorised persons in the passage direction and then close again after passage. Default position "day-operation" open: the door leaves close automatically if somebody tries to pass without authorisation. In the case of a power failure: door leaves can be moved freely! Control units and power supply unit are integrated in the unit. Power supply 100-120 V / 200-240 V 50-60 Hz Dowelled on finished floor level FFL. Not suitable for outdoor installation! Prot. class Housing IP43 components conducting supply voltage IP43. [/LIST]

[LIST] Passage width = 650 mm, total width = 1.050 mm, interlock height 1.020 mm, interlock length = 1.470 mm Housing made of stainless steel satin finish AISI 304. Two door leaves made of transparent polycarbonate, upper edge 900 mm. Stainless steel satin finish. Function Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Entrance sector monitored by a simple sensor system in short overall length (simple single passage monitoring in both directions, security level 0). Protective device: rotation angle of the door leaves is monitored by the same sensor system. operation mode: Default position "night-operation" closed: the door leaves open automatically for authorised persons in the passage direction and then close again after passage. In the case of a power failure: door leaves can be moved freely! Control units and power supply unit are integrated in the unit. Power supply 100-120 V / 200-240 V 50-60 Hz Dowelled on finished floor level FFL. Not suitable for outdoor installation! Suitable for escape routes if combined with emergency push button and escape route equipment (cf. general accessories). [/LIST]

[LIST] Passage width = 650 mm, total width = 1.070 mm, interlock height 945 mm, interlock length = 1.290 mm Guiding elements made of stainless steel AISI 304, Ø 60 mm, with 10 mm tempered safety glass panels and AISI 304 stainless steel bar handle. Integrated sensor system in respective handrail (L = 1290 mm / W = 130 mm / H = 45 mm). Two door leaves made of transparent polycarbonate, upper edge 900 mm. Drive housing made of stainless steel AISI 304. Stainless steel satin finish. Function Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Entrance sector monitored by a simple sensor system in short overall length (simple single passage monitoring in both directions, security level 0). Protective device: rotation angle of the door leaves is monitored by the same sensor system. operation mode: Default position "night-operation" closed: the door leaves open automatically for authorised persons in the passage direction and then close again after passage. In the case of a power failure: door leaves can be moved freely! Control units and power supply unit are integrated in the unit. Power supply 100-120 V / 200-240 V 50-60 Hz Dowelled on finished floor level FFL. Not suitable for outdoor installation! Suitable for escape routes if combined with emergency push button and escape route equipment (cf. general accessories). [/LIST]

[LIST] Passage width = 650 mm, total width = 1.070 mm, interlock height 945 mm, interlock length = 2.010 mm Guiding elements made of rectangular stainless steel posts AISI 304 with 8 mm tempered and satined safety glass panels and stainless steel bar handle AISI 304. Sensor system integrated in the guiding elements. The sensors are covered by the satined glass panels and infrared transmissible segments. Two door leaves made of transparent polycarbonate, upper edge 900 mm. Drive housing made of stainless steel AISI 304. Stainless steel satin finish. Function Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Entrance sector monitored by enhanced sensor system in optimised overall length and alignment (increased level of single passage monitoring in both directions, security level 2). Integrated protection against entry from below, identification of trolleys, detection of children. Protective device: rotation angle of the door leaves is monitored by the same sensor system. 2 operation modes are possible: Default position "day-operation" open: the door leaves close automatically if somebody tries to pass without authorisation Default position "night-operation" closed: the door leaves open automatically for authorised persons in the passage direction and then close again after passage In the case of a power failure: door leaves can be moved freely [/LIST]

[LIST] Passage width = 650 mm, total width = 1.070 mm, interlock height 945 mm, interlock length = 1.660 mm Guiding elements made of stainless steel AISI 304, Ø 60 mm, with 10 mm tempered safety glass panels and AISI 304 stainless steel bar handle. Integrated sensor system in respective handrail (L = 1660 mm / W = 130 mm / H = 45 mm). Two door leaves made of transparent polycarbonate, upper edge 900 mm. Drive housing made of stainless steel AISI 304. Stainless steel satin finish. Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Entrance sector monitored by a basic sensor system in compact overall length (fundamental single passage monitoring in both directions, security level 1). Protective device: rotation angle of the barrier door leaves monitored by the same sensor system. 2 operation modes are possible: Default position "day-operation" open: the door leaves close automatically if somebody tries to pass without authorisation. Default position "night-operation" closed: the door leaves open automatically for authorised persons in the passage direction and then close again after passage. In the case of a power failure: door leaves can be moved freely! Control units and power supply unit are integrated in the unit. Power supply 100-120 V / 200-240 V 50-60 Hz Dowelled on finished floor level FFL. Not suitable for outdoor installation! [/LIST]

[LIST] Passage width = 540 mm Housing made of stainless steel satin finish AISI 304. Base columns prepared for installation of a barrier tape, slot existing. Two door leaves made of colourless PETG, lightgrey rectangles, upper edge 1.000 mm. Total width = 990 mm Interlock height = 1520 mm Interlock length = 1700 mm Security and safety sensor system including luggage detection. 10 mm tempered safety glazing in the guide elements. Cut out in the bottom area of the lateral privacy glass, ESG 10 mm frosted for A4 paper. Without cut out for Printer. LVDS 7" display Stainless steel satin finish. traveler interface stainless steel satin finish entrance free after authorisation exit always closed Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube. Signal device (arrow/cross pictogram) on entry side. Acoustic signal to announce unauthorised entry. Lockable components with Kaba lock cylinders for maintenance cover and square for printer doors. Incorrent behaviour during Boarding (block lock for 5 seconds) standard tailgating IPC CV05 4GB RAM In the case of a power failure: door leaves can be moved freely! Control units and power supply unit are integrated in the unit. Power supply 100–240 VAC 50/60 Hz Dowelled on finished floor level FFL. Not suitable for outdoor installation! Prot. class Housing IP32 Components conducting supply voltage IP42 [/LIST]

[LIST] Tubular column made of stainless steel AISI 304, Ø 140, with U-shaped crossbars, Ø 40 mm, made of stainless steel tube AISI 304. Door leaf radius 900 mm, top edge of door leaf 900 mm Locking system, drive and toothed holding brake installed in tubular column. variant A: passage side inwards right. Stainless steel satin finish. Function Type 2 power-assisted motion; servo positioning drive / 2 directions electrically controlled, 90° opening in entrance and exit directions. Control system and power supply unit in an external switch cabinet H = 283 / W = 168 / D = 115 (mm). Power supply 100–240 VAC 50/60 Hz Doweled on finished floor level FFL, floor levelness according to DIN 18202 max. ± 2 mm. Suitable for outdoor installation! Prot. class Housing IP43, components conducting supply voltage IP54. Suitable for escape routes if combined with emergency push button and escape route equipment (cf. general accessories). Emergency button requires for additional card reader post. Card reader installation and signal lights integration in a separate reader post by customer. [/LIST]

[LIST] Tubular column made of stainless steel AISI 304, Ø 140, with high element made of 10 mm tempered safety glass and straight stainless steel bar handle. Door leaf radius 900 mm, top edge of door leaf 900 mm. Door leaf radius 900 mm, top edge of door leaf 900 mm Locking system, drive and toothed holding brake installed in tubular column. variant A: passage side inwards right. Stainless steel satin finish. Function Type 2 power-assisted motion; servo positioning drive / 2 directions electrically controlled, 90° opening in entrance and exit directions. Control unit in external switch cabinet H = 283 / W = 168 / D = 115 (mm). Power supply 100–240 VAC 50/60 Hz Doweled on finished floor level FFL, floor levelness according to DIN 18202 max. ± 2 mm. Not suitable for outdoor installation! Suitable for escape routes if combined with emergency push button and escape route equipment (cf. general accessories). Emergency button requires for additional card reader post. Card reader installation and signal lights integration in a separate reader post by customer. [/LIST]

[LIST] Tubular column made of stainless steel AISI 304, Ø 140, with flat steel bar to clamp the high element made of 10 mm tempered safety glass and straight stainless steel bar handle. Door leaf radius 900 mm, top edge of door leaf 1800 mm Locking system, drive and toothed holding brake installed in tubular column. variant A: passage side inwards right. Stainless steel satin finish. Function Type 2 power-assisted motion; servo positioning drive / 2 directions electrically controlled, 90° opening in entrance and exit directions. Control unit in external switch cabinet H = 283 / W = 168 / D = 115 (mm). Power supply 100–240 VAC 50/60 Hz Doweled on finished floor level FFL, floor levelness according to DIN 18202 max. ± 2 mm. Not suitable for outdoor installation! Prot. class Housing IP43, components conducting supply voltage IP54. Suitable for escape routes if combined with emergency push button and escape route equipment (cf. general accessories). Emergency button requires for additional card reader post. Card reader installation and signal lights integration in a separate reader post by customer. [/LIST]

[LIST] Total height = 2.300 mm, passage height = 2.100 mm, upper body part = 200 mm Body metal cladded side panels with steel or stainless steel sub-structure, alternatively with glazing (see below). Safety strips on opposite shearing edges. Top dust-proof cover made of raw aluminium plate. Two maintenance openings in the lower ceiling plate (outer opening can be locked by means of customer's profile half cylinder). Rotating unit with all-round aluminium profiles T56 mm. For glazing see below. With sealing brushes. Black U-shaped handles. Horizontal and vertical safety strips at the door leaves. Powder-coated in an RAL colour. PR-1 drive to regulate the position for automatic access control. Starts with a manual push after release signal. Sensor system in the ceiling monitores the barrier segment, incl. release-button. In the case of a power failure: end point locking system locked. Signal display red/green (for 180° partition) in a stainless steel console attached to the inside and outside of the corner profile. One emergency off switch installed at the corner profile (inside). If night slides outside are present, they are installed on the reader post or night slide wings (electrical adapter kit for NS required). Control system integrated in the unit. Power supply 230 V 50 Hz. Installation on finished floor level FFL, floor levelness according to DIN 18202 max. ± 2 mm. [/LIST]

[LIST] Total height = 2.300 mm, passage height = 2.100 mm, upper body part = 200 mm Body Side panels with glazing (see below), alternatively with metal cladding. Thermal separation of body elements on façade level. Safety strips on opposite shearing edges. Top dust-proof cover made of raw aluminium plate. Two maintenance openings in the lower ceiling plate (outer opening can be locked by means of customer's profile half cylinder). Rotating unit with all-round aluminium profiles T40. For glazing see below. With sealing brushes. Black U-shaped handles. Horizontal and vertical safety strips at the door leaves. Finish Powder-coated in an RAL colour. PR-1 drive to regulate the position for automatic access control. Starts with a manual push after release signal. Sensor system in the ceiling monitores the barrier segment, incl. release-button. In case of power failure: end point locking system turns freely or is locked, as desired. Generally locked for WK. Signal display red/green (for 180° partition) in a stainless steel console attached to the inside and outside of the corner profile. One emergency off switch installed at the corner profile (inside). If night slides outside are present, they are installed on the reader post or night slide wings (electrical adapter kit for NS required). Control system integrated in the unit. Power supply 230 V 50 Hz. On finished floor level FFL, floor levelness according to DIN 18202 max. ± 2 mm. [/LIST]

[LIST] Total height = 2.260 mm, passage height = 2.100 mm Body side panels with glass and filigree profiles, glass ceiling made of laminated safety glass. Thermal separation of body elements on façade level. Safety strips on opposite shearing edges. Subsurface installation of electric and mechanical components. Rotating unit T25 without central column or profile, tempered safety glass or T40 (in WK2), P4A glazing. Black U-shaped handles. Horizontal and vertical safety strips at the door leaves. Powder-coated in an RAL colour. PR-1 drive to regulate the position for automatic access control (subsurface, for WK 2 a secured compartment is necessary). Starts with a manual push after release signal. Sensor system in the ceiling (intermediate crossbar) and 1-zone contact mat/s with black rubber floor covering monitor the barrier segment/s (observe the restricted installation options for the sensor system), incl. release-button/s. In case of power failure: end point locking system turns freely or is locked, as desired. Generally locked for WK. Signal display red/green (for 180° partition) in a stainless steel console attached to the inside and outside of the corner profile. One emergency off switch installed at the corner profile (inside). If night slides outside are present, they are installed on the reader post or night slide wings (electrical adapter kit for NS required). Electric Control unit installed subsurface. Power supply 230 V 50 Hz. [/LIST]

[LIST] Total height = 2.300 mm, passage height = 2.100 mm, upper body part = 200 mm Body side panels with 8 mm laminated safety glass. Thermal separation of body elements on façade level. Top dust-proof cover made of raw aluminium plate. Bottom ceiling plate star-shaped, non-visible mounting, removable for inspection work. Two-winged inside and outside, with all-over aluminium profiles and 8 mm laminated glass panels. Finish Powder-coated in an RAL colour. 2 drives with control unit and with 6 infrared motion detectorsin for open automaticially in upper part of the body. 2 central operation panels to be installed by customer with the following functions: AUTOMATIC SUMMER - automatic operation, the door wings are not locked => day operation, AUTOMATIC WINTER - automatic operation with reduced opening angle, the door wings are not locked => day operation, OPEN - the door wings open and stay open, ONE WAY - only passage in one direction => day operation, NIGHT - the outer door wings are locked and can only be opened by a command as designated by customer, MANUAL OPERATION - the door wings are unlocked and can be moved manually. Protection of closing motion by means of light curtain on outer radius (PH max. 3.000). Locking system outside by means of Veri-S (not for redundant units, in this case kept closed via motor power). In case of power failure the outer door wings are battery operated for 30 minutes. [/LIST]

[LIST] Total height = 2.300 mm, passage height = 2.100 mm, upper part of the body = 200 mm Body side panels with 8 mm laminated safety glass Thermal separation of body elements on façade level. Top dust-proof cover made of raw aluminium plate. Bottom ceiling plate star-shaped, non-visible mounting, removable for inspection work. Two winged, framed all-around with aluminium profiles and 8 mm laminated glass. Powder-coated in an RAL colour. 1 drive with control unit in upper part of the body and with 3 infrared motion detectors. 1 central operation panel to be installed by customer with the following functions: AUTOMATIC SUMMER - automatic operation, the door wings are not locked => day operation, AUTOMATIC WINTER - automatic operation with reduced opening angle, the door wings are not locked => day operation, OPEN - the door wings open and stay open, ONE WAY - only passage in one direction => day operation, NIGHT - the door wings are locked and can only be opened by a command as designated by customer, MANUAL OPERATION - the door wings are unlocked and can be moved manually. Protection of closing motion by means of light curtain on outer radius (PH max. 3.000). Locking system by means of Veri-S (not for redundant units, in this case kept closed via motor power). In case of power failure the door wings are battery operated for 30 minutes. Last function: opening or closing of door wings. Control system integrated in the unit. [/LIST]

[LIST] Total height = 2.300 mm, passage height = 2.100 mm, upper body part = 200 mm Body side panels with 8 mm laminated safety glass, alternatively metal cladding. Thermal separation of body elements on façade level. Top dust-proof cover made of raw aluminium plate. Two maintenance openings in the lower ceiling plate (For DL option, outer opening can be locked by means of customer's profile cylinder). Rotating unit four-leaf 180°, all-round aluminium profiles T40 with sealing brushes. Tempered safety glass. Black U-shaped handles. Bolt lock (installed on top of door leaf) prepared for profile cylinder provided by customer to fix the rotating unit. Powder-coated in an RAL colour. Can be rotated freely manually, smooth-running. Mounted on finished floor level FFL, floor evenness ± 2 mm (in the case of floor unevenness, we recommend you install a floor element). [/LIST]

[LIST] Total height = 2.400 mm, passage height = 2.200 mm, upper body part = 200 Body side panels with 8 mm laminated safety glass, alternatively metal cladding. Safety strips on opposite shearing edges. Top dust-proof cover made of raw aluminium plate. Maintenance openings in the lower ceiling plate. Rotating unit four-leaf 180°, fixed, on centrical bearings, all-round aluminium profiles T56 mm with sealing brushes. Tempered safety glass. Without handles. Horizontal and vertical safety strips at the door leaves. Two bar bolts prepared for customer's profile cylinder. Powder-coated in an RAL colour. SA3 servo drive with OPL 03 (choice between aluminium or stainless steel), rotates at walking speed. Start by means of infrared sensors. 2 x pre-sensors, installed in ceiling plate. One emergency off switch installed at the corner profile (inside). If night slides outside are present, they are installed on the reader post or night slide wings (electrical adapter kit for NS required). Two push-buttons, Ø 20, for those with reduced mobility. Control system integrated in the unit. Power supply 230 V 50 Hz. Mounted on finished floor level FFL, floor evenness ± 2 mm (in the case of floor unevenness, we recommend you install a floor element). [/LIST]

[LIST] Total height = 2.300 mm, passage height = 2.100 mm, upper body part = 200 mm Body side panels with 8 mm laminated safety glass, alternatively metal cladding. Thermal separation of body elements on façade level. Safety strips on opposite shearing edges. Top dust-proof cover made of raw aluminium plate. Two maintenance openings in the lower ceiling plate (For DL option, outer opening can be locked by means of customer's profile cylinder). Rotating unit four-leaf 180°, on centrical bearings, emergency escape function (protection against trespassing approx. 2.000 Nm), activation by means of inside emergency off-switch, includes break-out symbols to be glued on the door leaves. Emergency escape function: test number 07 780 553606 (TÜV Nord). All-round aluminium profiles T56 mm with sealing brushes. Black U-shaped handles. Horizontal and vertical safety strips at the door leaves. Two bar bolts to lock the rotating unit to the top and to the bottom. Powder-coated in an RAL colour. Fully automatic K8-SA1 with OPL 01 (for option "DL1", open when no power available is advisable) and KGB emergency escape module. Start by means of infrared sensors. Reverse push-button in the entrance sectors. One emergency off switch installed at the corner profile (inside). If night slides outside are present, they are installed on the reader post or night slide wings (electrical adapter kit for NS required). Two push-buttons, Ø 20, for those with reduced mobility. [/LIST]

[LIST] Total height = 2.300 mm, passage height = 2.100 mm, upper body part = 200 mm Body side panels with 8 mm laminated safety glass, alternatively metal cladding. Thermal separation of body elements on façade level. Top dust-proof cover made of raw aluminium plate. Two maintenance openings in the lower ceiling plate (For DL option, outer opening can be locked by means of customer's profile cylinder). Body side panels with 8 mm laminated safety glass, alternatively metal cladding. Rotating unit four-leaf 180°, all-round aluminium profiles T40 with sealing brushes. Tempered safety glass. Black U-shaped handles. Bolt lock (installed on top of door leaf) prepared for profile cylinder provided by customer to fix the rotating unit. Powder-coated in an RAL colour. Can be rotated freely manually, smooth-running. Mounted on finished floor level FFL, floor evenness ± 2 mm (in the case of floor unevenness, we recommend you install a floor element). [/LIST]

[LIST] Total height = 2.230 mm, passage height = 2.100 mm, upper body part = 130 mm Body side panels with 8 mm laminated safety glass. Thermal separation of body elements on façade level. Glass ceiling consisting of 2 laminated safety glass segments, all-round framing according to TRLV (technical rules for the use of linear shaped glazing), maximum outside diameter for T25 is 3300 mm, at T40 to 3700 mm. Rotating unit four-leaf 180°, without central profile, all-round aluminium profiles T25 mm (till Ø3300) with sealing brushes (T40 off Ø3400). Tempered safety glass. Black U-shaped handles. Bar-lock for profile cylinder provided by customer (closing downwards) to fix the rotating unit. Powder-coated in an RAL colour. Can be rotated freely manually, smooth-running. Mounted on finished floor level FFL, floor evenness ± 2 mm (in the case of floor unevenness, we recommend you install a floor element). [/LIST]
